华为交换机console口登录账号密码设置案例
一、配置需求
1、配置S5700-核心交换机console口登录需要密码验证
2、配置S5700-核心交换机console口登录需要账号和密码验证
二、配置步骤
2.1、配置S5700-核心交换机console口登录需要密码验证步骤
2.1.1、进入系统视图
<Huawei>sys
<Huawei>system-view
Enter system view, return user view with Ctrl+Z.
[Huawei]
2.1.2、进入Console用户界面视图
[Huawei]user-interface console 0
[Huawei-ui-console0]
2.1.3、设置用户验证方式为密码验证
[Huawei-ui-console0]authentication-mode ?
aaa AAA authentication
none Login without checking
password Authentication through the password of a user terminal interface
[Huawei-ui-console0]authentication-mode password
[Huawei-ui-console0]
2.1.4、设置验证密码，输入的密码可以是明文或密文
[Huawei-ui-console0]set authentication password ?
cipher Set the password with cipher text
simple Set the password in plain text
[Huawei-ui-console0]set authentication password cipher ?
STRING<1-16>/<24> Plain text/cipher text password
[Huawei-ui-console0]set authentication password cipher wlgcs.cn
[Huawei-ui-console0]
[Huawei-ui-console0]q
[Huawei]q
<Huawei>sa
2.2、配置S5700-核心交换机console口登录需要账号和密码验证
2.2.1、设置用户验证方式为AAA验证
[Huawei-ui-console0]authentication-mode ?
aaa AAA authentication
none Login without checking
password Authentication through the password of a user terminal interface
[Huawei-ui-console0]authentication-mode aaa
[Huawei-ui-console0]
2.2.2、退出Console用户界面视图，进入AAA视图
[Huawei-ui-console0]qu
[Huawei]aaa
[Huawei-aaa]
2.2.3、配置登录账号名和密码
[Huawei-aaa]local-user ?
STRING<1-64> User name, in form of 'user@domain'. Can use wildcard '*',
while displaying and modifying, such as *@isp,user@*,*@*.Can
not include invalid character / \ : * ? " < > | @ '
[Huawei-aaa]local-user wlgcs password ?
cipher User password with cipher text
simple User password with plain text
[Huawei-aaa]local-user wlgcs password cipher ?
STRING<1-16>/<24> The UNENCRYPTED/ENCRYPTED password string
[Huawei-aaa]local-user wlgcs password cipher wlgcs.cn
Info: Add a new user.
[Huawei-aaa]
2.2.4、配置账号的接入类型为Console用户
[Huawei-aaa]local-user wlgcs ?
access-limit Set access limit of user(s)
ftp-directory Set user(s) FTP directory permitted
idle-timeout Set the timeout period for terminal user(s)
password Set password
privilege Set admin user(s) level
service-type Service types for authorized user(s)
state Activate/Block the user(s)
[Huawei-aaa]local-user wlgcs service-type ?
8021x 802.1x user
bind Bind authentication user
ftp FTP user
http Http user
ppp PPP user
ssh SSH user
telnet Telnet user
terminal Terminal user
web Web authentication user
x25-pad X25-pad user
[Huawei-aaa]local-user wlgcs service-type terminal
[Huawei-aaa]
[Huawei-aaa]q
[Huawei]q
<Huawei>sa
三、配置验证
3.1、验证S5700-核心交换机console口登录需要密码
Please Press ENTER.
Login authentication
Password: # 输入密码wlgcs.cn 回车登录
<Huawei>
3.2、验证S5700-核心交换机console口登录需要账号和密码
Please Press ENTER.
Login authentication
Username:wlgcs
Password: # 输入密码wlgcs.cn 回车登录
<Huawei>
四、配置信息
4.1、S5700-核心交换机console口登录需要密码验证配置信息
#
user-interface con 0
authentication-mode password
set authentication password cipher =!|}D)F/uV:.`&R&e7S(W>A#
user-interface vty 0 4
#
4.2、S5700-核心交换机console口登录需要账号和密码验证配置信息
#
aaa
authentication-scheme default
authorization-scheme default
accounting-scheme default
domain default
domain default_admin
local-user admin password simple admin
local-user admin service-type http
local-user wlgcs password cipher )UB'#XU&R,=NZPO3JBXBHA!!
local-user wlgcs service-type terminal
#
user-interface con 0
authentication-mode aaa
set authentication password cipher =!|}D)F/uV:.`&R&e7S(W>A#
user-interface vty 0 4
#
